SPECS…
| AXLE | (2) 8,000# Quick Lubricating w/Electric Brakes |
|---|---|
| JACK | 12,000# Top Wind Drop Leg Jack (BP), Dual 12,000# Drop Leg – Side Wind (GN) |
| TIRE | ST215/75 R-117.5 Load Range H |
| FLOOR | 2″ Treated Pine or Douglas Fir* |
| FRAME | 8″ I-Beam, 10# (13# on 26 Model) |
| WHEEL | 17.5″ x 6″; Black Mod 8 Bolt |
| FINISH | Superior Quality Finish is Applied for a Highly Decorative and Protective Finish |
| LIGHTS | L.E.D. D.O.T. Stop, Tail, Turn & Clearance |
| TONGUE | Integral w/ Frame |
| COUPLER | Adjustable Cast 2-5/16″ 18,000# Demco EZ Latch (BP) 2-5/16″ Round Adj. Pin (25K) (GN) |
| G.V.W.R. | 17500# |
|---|---|
| TOP RAIL | None |
| ELEC. PLUG | 7-Way RV |
| HITCH TYPE | Bumper Pull |
| SIDE RAILS | 6″ x 2″ x 1/8″ Rectangular Tubing w/Stake Pockets & Rubrail on Both Sides |
| SUSPENSION | Multi-Leaf Slipper Spring w/Equalizer |
| CROSSMEMBERS | 3″ Channel |
| FINISH (Prep) | Steel is Cleaned to Ensure a Professional Smooth Finish |
| SAFETY CHAINS | 3/8″ Grd. 70 w/Safety Latch Hook (2 each) |
| G.A.W.R. (Ea. Axle) | 7,000# |
THE 14OT ALSO COMES EQUIPPED WITH:
- Adjustable Cast 2-5/16″ Demco EZ Latch Coupler
- Adjustable Cast 2-5/16″ Coupler, * Round Adjustable Pin 2-5/16″ on Gooseneck Model
- 8″ I-Beam Frame w/Integrated Tongue
- 12,000# Drop-Leg Jack, Top Wind
- *Dual Jacks on Gooseneck Model
- Lockable Pump & Battery Box Mounted in Front of Bed
- Rubrail and Stake Pockets Along Sides
- Self Contained Electric/Hydraulic Scissor Hoist
- Power Up/Power Down Hydraulic Pump
- 12V Interstate Deep Cycle Battery
- 110V On-Board Battery Charger (5 Amp)
- Premium Brand Axles
- Cambered Axles w/ Quick Lubricating Hubs
- Forward Self Adjusting Electric Brakes
- L.E.D. Lighting Package
- Sealed Modular Wiring Harness
- Spare Tire Mount (In Tongue Area)
- Complete Break-A-Way System w/Charger
- Zip Break-A-Way Cable
- Radial Tires
- Recessed Winch Plate at Front of Deck
- Rear Diamond Plate Knife Edge w/Collapsible Bumper
We’ve got the Big Tex 8.5×24 Tilt Trailer priced to move at $13,499 with NO SETUP or DOC FEES!
